TCS
10163
Clamping force 200 ton
Opening force 85 ton
Sliding table dimensions 3.000 x 2.300 mm
Table stroke 2.320 mm
Max weight on sliding table 60 ton
Max weight on tilting table 30 ton
Upper table rotation 115°
Max daylight between platens 2.750 ...
IMS
07639
Punching diameter 28x20 mm
Slotting 90x52x12 mm
Angular cutting 90 degrees, 130x130x13 mm
Bars cutting diameter 45 mm
Shear 450x15 mm/300x20 mm
USED MACHINE
Table Data:
Capacity | 2500M
Table area | 1500x350mm
Number of “T” shaped slots | 5-16H7
Distance between “T” shaped slots | 60mm
Rotary movement of table in both direction | 45º
Automatic longitudinal | 1150mm
Automatic cross | 400mm
Auto...
