MORI SEIKI
10213
WITH Y AXIS
Turning diameter 755 mm
Machinable diameter 390mm
Machinable length 655 mm
Turret 12 motorized stations
Y-axis + / - 60 mm
C-axis
Spindle A2-8
Kitagawa B-210 250 mm
Rpm 3,500
Spindle motor 18.5 Kw
Motorized tool motors 5.5 Kw
Rpm 4,000
Bar passage 75 mm
Tailstock MT5
Rapid traverse speeds of 18 and 24 m/min on X and Z axes
Weight 5,800 Kg
Complete with:
- Hydraulic and programmable tailstock
- Prismatic guides
- Chip conveyor
- Oil cooling for head
- Renishaw automatic tool measuring arm.
- Automatic stress control and tool wear monitoring.
- Installation interface for bar loader.
- Automatic workpiece collector
- Dual foot pedals for opening and closing the main and tailstock plates.
USED MACHINE.
FICEP
08464
CNC HOLE DRILLING TYPE 1003 DZB:
Working profiles Flats-L-U-H
Max drilling diameter 40 mm (R520N / mm2)
Max thickness 50 mm
Max weight 540 kg
SAW MACHINE TYPE SGB 1045:
Cutting capacity at 90 degrees max/min mm 1015x450/80x10
Cutting capa...
OMBA
07003
CNC ECS 4802 (RECONDITIONED YEAR 2006)
DIAMETER HYDRAULIC SPINDLE MM 900
TURNING DIAMETER MM 1100
MAX HEIGHT UNDER CROSSRAIL MM 1150
FEED MOTOR CONSTANT TORQUE da Nm 1,8
SPEED RAPID TRAVERSE MM/MIN 8000
SECTION OF TOOLS MAX MM 40X40
SPEED ...
