MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Titan
  • Model:
  • Titan Umaro CNC VTL Model SC33 3000mm
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • N/A

DESCRIPTION

Titan Umaro CNC VTL Model SC33 Retrofitted 2011 – Siemens 84D Control Maximum turning diameter – 3300mm Table diameter – 3000mm Maximum height of workpiece – 2270mm Max Ram Travel – 1250mm Size of ram – 224mm x 224mm Number of steps of the gear box 3 Working feed range – 0.05 – 5mm/rev Rapid traverse – 2.500mm/min Main motor power – 55kW Maximum table load – 18000kg Dimensions: 5760mm x 6282mm x 6500mm Weight: 48000kg
+ request more information
