NAVA
09443
Max ram force 250 tons
Max blank holder force 125 tons
Max ram stroke 800 mm
Max blank holder stroke 350 mm
Max ram pressure Kg/cm2 220
Max blank holder pressure Kg/cm2 255
Ram planes dimensions 1600x1200 mm
Blank holder planes dimensions ...
IMTS
07651
CNC ECS 2400
Swing diameter over bed mm 880
Max turning diameter over bed mm 740
Longitudinal stroke (axis Z) mm 2200
Cross stroke (axis X) mm 450
Max turning lenght mm 2200
Distance between center mm 2200
Sindle taper ASA 11''
SPindle bor...
GRAZIANO
09407
Height of center (on the bed) mm 190
Height of center (on the gap) mm 250
Height of center (on the carriage) mm 120
Distance between mm 1000
Bar passaging mm 52
EQUIPPED WITH:
COMPLETO DI:
-Self centering chuck Pinto diam. mm 200 3+3+3...
