PBR
10006
Height of centers mm 450
Max turning diameter on the bed mm 930
Max turning diameter on the cross carriage mm 600
Max turning diameter on the recess mm 1220
Bench width mm 630
Distance between centers mm 4000
Spindle attachment nose ASA 11'...
ONA
09651
TABLE:
Tank size mm 1700x1000x600
Table dimensions mm 1200x800
Max table load Kg 4000
Max height piece mm 530
CROSS TABLE:
Longitudinal X stroke mm 1000
Cross Y stroke mm 600
HEAD:
Electrode-holder stroke 500 mm
Max electrode weight 400 kg
...
