MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Tschudin
  • Model:
  • 022202 - TSCHUDIN TS 45 A
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Centre height: 100 mm.
Distance between centres: 430 mm.
Max. grinding diameter: 198 mm.
Grinding length: 400 mm.
Max. work piece diameter: 198 mm.
Min. work-piece diameter: 1 mm.
Z axis: 480 mm.
X axis: 340 mm.
Workpiece weight on centres max.: 100 kg.
Diameter: 500 mm.
Width: 3300 mm.
Peripheral speed: 45 m/s.
from: 20 t/min.
up to: 1000 t/min.
Holding taper:: 5 CM.
rotatable: +30 / 45 °.
Taper in tailstock:: 3 CM.
Tailstock travel of barrel: 20 mm.
Oscillation speed: 8000 mm/min.
Air connect: 6 bar.
Voltage 50 Hz 3x: 400 Volt.
Grinding spindle motor: 7.5 kW.
Workpiece spindle motor: 3 kW.
Total power required: 16 kVA.
Machine's weight about: 4500 kg.
Length: 3700 mm.
Height: 2500 mm.
