FIAT
07074
CAPACITY:
Max drilling diameter on cast iron R=25 mm 60
Max drilling diameter on steel R=50 mm 50
Arm lenght mm 1000
Arm vertical stroke mm 700
SPINDLE:
Diameter mm 80
Automatic stroke mm 355
Cono Morse N.4
Spindle speed n.13 - rpm 45:2800...
Control System: Fanuc Oi-MDMaximum workpiece size: 800kgTable Size: 1150 x 490mmTraverses XYZ: 1020mm x 610mm x 610mmCutting Feedrate: 20m/minuteRapid Feedrates XYZ: 43 x 43 x 36m/minMax Height Under Spindle: 100-710mmSpindle Motor Power: 11kWSpindle...
Quantitative Production by 3 Milling Turrets with Y-axis! 3rd turret (lower turret) minimizes the cutting time difference between OP-10 and OP-20 to balance cutting tempo. 3rd turret offers sufficient 32 tools for both OP-10 and OP-20 machining appli...
Capacity between Centres 54”. Swing over Bed ways 24”. Swing over Cutter Carriage 12”. Min/Max Longitudinal Distance Nose of Work Spindle to Centre of Cutter Swivel Head 7”/55”. Min/Max Axial Distance Centre of Work Spindle to Centre of...
