MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Elb
  • Model:
  • 008287 - ELB Optimal 2 VA II
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Table length: 900 mm.
Table width: 250 mm.
Grinding length: 650 mm.
Grinding width: 375 mm.
Grinding height: 300 mm.
Table load max.: 280 kg.
Longitudinal travel (X-axis): 700 mm.
Transversal travel (y axis): 350 mm.
from: 1500 t/min.
up to: 3000 t/min.
Diameter of grinding wheel: 300 mm.
Width of the grinding wheel: 50 mm.
Wheel int. diameter: 76.2 mm.
number (steps): 2.
Voltage 50 Hz 3x: 380 Volt.
Grinding spindle motor: 3.7/4.5 kW.
Machine's weight about: 4000 kg.
Length: 600 mm.
Width: 300 mm.
Height: 2400 mm.
