MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • LEISTRITZ
  • Model:
  • 022301 - LEISTRITZ RR 120 BHF
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Min. diameter threaded: 2 mm.
Max. diameter threaded: 50 mm.
Min. pitch: 0.35 mm.
Max. pitch: 3 mm.
Max. infeed length: 85 mm.
Min. roll die diameter: 120 mm.
Roll die width: 90 mm.
Roller pressure infinitely adjustable: 12 to.
Roll axis swivel for thru-feed: 8 °.
Max. working stroke: 125 mm.
from: 30 t/min.
up to: 150 t/min.
Voltage 50 Hz 3x: 400 Volt.
Motor power: 7.5 kW.
Connection power: 8 kW.
Machine's weight about: 2000 kg.
Length: 1440 mm.
Width: 1260 mm.
Height: 1805 mm.
