Reference: 2190079
| Manufacturing origin | Swiss |
| Voltage | 380/50/3 |
| Netweight | abt. 1100 kg |
| Dimensions | abt. 1500x1340x1600 mm |
| Customs position | 8460.29 20 |
| Max. stroke on slide-way | 530x210 mm |
| Max grinding capacity | 530x230 mm |
| Usable table surface | 600x200 mm |
| Longitudinal slide-way speed, continuous | 0-21 m/min |
| Transverse slide-way speed, continuous | 0-9 m/min |
| Vertical move | 250 mm |
| Max. way between new grinding-wheel and table | 250 mm |
| Vertical movement | |
| On handwheel, 1 division | 0,01 mm |
| On micrometric device, 1 division | 0,001 mm |
| Automatic | 0,005-0,10 mm |
| Transverse movement | |
| On handwheel, 1 division | 0,01 mm |
| With comparator | 0,001 mm |
| Grinding-wheel | |
| Diameter x width x bore | 225 x 25 x 50 mm |
| Normal speed | 2700 rpm |
| Speed with variator | 2700-1000 rpm |
| Motors | |
| of spindle | 3000 rpm 2,5 HP |
| of hydraulic pump | 1500 rpm 0,75 HP |
| of cooling pump | 2800 rpm 0,15 HP |
| errors and omissions excepted-data given without obligation | |
