Cast iron plain tooling cube with mounting holes. Plain to allow for the machining of hole patterns and features required for specific fixtures. Ground flat parallel and perpendicular for accuracy. Holes for side location to allow precise loading and...
MIKRON
09641
Heidenhain iTNC 530 CNC
TRAVEL:
X axis 1000 mm
Y axis 650 mm
Z axis 500 mm
TABLE:
Table size: 1300 x 600 mm
Max. Piece weight 1.600 kg
SPINDLE:
Spindle speed 20,000 rpm
Motor power 15 Kw
Spindle taper SK40
TOOL CHANGE:
Automatic 30-place...
Faceplates form the base for a fixture to mount directly to the QwikLOK. They are ideal for complex workpieces that cannot be mounted in soft jaws and also allow smaller workpieces to be clamped in larger quantities. Combine a faceplate with simple w...
